CI Home H65-R
6-1/2 Round In-Ceiling, 2-driver 2-way, ABS chassis/mounting clamps...
View all
Specifications
-
Finishes
White, paintable grille
-
Crossover
2nd-order electro-acoustic at 3.0 kHz
-
Frequency Response
±2 dB from 70 Hz - 20 kHz
-
Frequency Response 30° Off-Axis
±2 dB from 70 Hz - 18 kHz
-
High Frequency Driver
3/4" (1.9cm) PTD™ dome
All specifications
Paradigm CI Home H65-R Active Ceiling Speaker
6-1/2 Round In-Ceiling, 2-driver 2-way, ABS chassis/mounting clamps
General
Design
2-driver, 2-way in-ceiling, ABS chassis & mounting clamps
Finishes
White, paintable grille
Functions
Crossover
2nd-order electro-acoustic at 3.0 kHz
Frequency Response
±2 dB from 70 Hz - 20 kHz
Frequency Response 30° Off-Axis
±2 dB from 70 Hz - 18 kHz
High Frequency Driver
3/4" (1.9cm) PTD™ dome
Impedance
Compatible with 8 ohms
LOW FREQUENCY EXTENSION
55 Hz
Mid/Bass Frequency Driver
6.5" (16.5cm) mineral-filled polypropylene cone
Sensitivity
89 dB / 85 dB
Inputs
Power
Dimensions
Cut Out Dimensions
7.75" (19.7cm) Diameter
Mounting Depth
3" (7.6cm)
Overall Dimensions
8.75" (22.2cm) Diameter 3.625" (9.2cm) Depth
