Designed to suit 50-60" TV screens the SB-3 is a passive soundbar which combines left, centre and right speakers into one low profile design which sits perfectly below any modern screen. Utilising Monitor Audio's advanced driver technologies The SB-3...
View all
Specifications
- Recommended Amplifier Requirements (W) All Channels: 30 - 100
- Recommended High Pass Crossover Frequency All Channels: 80 - 120Hz
- Frequency response (+/-3dB) All Channels: 80Hz - 30kHz
- Nominal Impedance (ohms) All Channels: 8
- Power Handling Single - R.M.S. (W) Left and Right Channels: 40 Centre Channel: 80
We also offer you
Free selection of cables
0 GBP
Connection and setup
Call an expert
Monitor Audio SB-3 Passive Soundbar, Black
Designed to suit 50-60" TV screens the SB-3 is a passive soundbar which combines left, centre and right speakers into one low profile design which sits perfectly below any modern screen. Utilising Monitor Audio's advanced driver technologies The SB-3 delivers flawless front channel audio using its 4" C-CAM mid range drivers, 1" C-CAM tweeters and specially designed auxiliary bass radiators to back up the low-end.
In larger rooms the SB-3 can be used with a partnering Monitor Audio subwoofer to deliver the best possible audio experience. Within smaller environments and systems, the SB's will deliver effortless full range audio way beyond the limits of any TV's sound system. Please note that as this is a passive soundbar it can only act as a replacement for front left, centre and right speakers in a surround system. It will require an AV receiver to drive it and will not function on its own, if you have any questions please contact our team who will be happy to advise you.
Individual C-CAM (Ceramic-Coated Aluminium/Magnesium) bass/mid driver for left and right channels, twin drivers for the centre channel
C-CAM gold dome tweeters per channel
Individual Auxiliary Bass Reflex (ABR) for left and right channels, twin ABRs for the centre channel
Three separate driver arrays for left, centre, right channels in a single cabinet
Optional dedicated wall bracket
Integrated Silicon feet provide a secure cabinet-top mounting alternative.
Specifications
Features
Recommended Amplifier Requirements (W)
All Channels: 30 - 100
Recommended High Pass Crossover Frequency
All Channels: 80 - 120Hz
Functions
Drive Unit
Left and Right Channels: 2 x 4" (100mm) C-CAM cone bass/mid driver
2 x 1" (25mm) C-CAM gold dome tweeter
Centre Channel: Left and Right Channels: 2 x 4" (100mm) C-CAM" cone bass/mid driver
1 x 1" (25mm) C-CAM gold dome tweeter
Frequency response (+/-3dB)
All Channels: 80Hz - 30kHz
Nominal Impedance (ohms)
All Channels: 8
Sensitivity
Left and Right Channels: 84dB
Centre Channel: 87dB
Power
Power Handling Single - R.M.S. (W)
Left and Right Channels: 40
Centre Channel: 80
System Power Handling - R.M.S. (W)
All Channels: 100 (High pass filter set to 100Hz)
Dimensions
Dimensions
145 x 1310 x 100mm
(511/16 x 519/16 x 315/16 inch)
Weight
9.1Kg
(20lb)
Monitor Audio
From the very first speaker, the iconic MA1, the brand developed, innovated, designed and refined, with a pioneering approach that saw patent after patent filed. It’s an ethos that hasn’t changed at all. In fact, Monitor Audio is one of very few high-end audio brands still developing new, cutting-edge technologies today.
